Elanus Duo - Ready to Fly

from 3,639.00

Airframe Features:

  • Weight (empty) - 5.3 lb

  • Weight (maximum) - 14 lb

  • Wingspan - 67 in

  • Flight Time - 2.5+ hours

  • Flight Time (LR kit) - 5.5 hours

  • Flight Distance - 120 miles (210 LR kit)

  • Cruise Speed - 40 mph

  • Wind Tolerance - 20mph (+10mph gust)

  • Launch - Hand Launch

  • Recovery - Belly Landing

  • Autopilot - Cube (Pixhawk 2.1)

See our videos here:

The LR (Long Range) kit includes custom tuned FOC ESC’s, lithium-ion batteries, and upgraded radios for maximum endurance for extreme jobs.

Options:
Camera:
Quantity:
Add To Cart

Standard Payload Features:

  • Camera - Sony A6000
  • Sensor - 24mp APS-C
  • Lens - 16mm E-Mount
  • GSD (400ft) - 3 cm
  • Triggering - Multiport to autopilot
  • Feedback - Hotshoe Shutter Logging
  • Power Supply - External (replaces battery)
  • Coverage (75% sidelap) - 700 ac/hr
  • Coverage (60% sidelap) - 1100 ac/hr



Notes:

  • Approximate standard radio range is at least 1 mile
  • Visual Line of Sight distance may be less depending on atmospheric conditions
  • Elanus Duo will be flight tested prior to shipping
  • Shipping and transportation is in molded styrofoam withing cardboard box (44"x11x17)
  • The USB telemetry transmitter will be included for mission upload and monitoring
  • A GCS with a USB port will be required. Laptops work well, but tablets may also work
  • Plane will be installed with Arduplane 3.9 dev for the latest features
  • Camera will be semi-permanently installed in a custom mount
  • Airframe includes 1 additional spare set of props, and spinners will only be included on the LR option
  • 2 batteries will be shipped separately direct from the manufacturer (to avoid shipping hazardous materials)
  • 110V AC Battery charger included, can also be attached to 12v vehicle battery for field charging (dongle required)
  • Spare parts will be published here soon!
